Floor Bracket 160 for 40-Series I-Type Aluminium Profiles

The Floor Bracket 160 is a robust base/floor element designed to anchor aluminium profile frames to concrete or steel floors. Engineered for 40-series I-Type (Slot 8) T-slot systems, it provides a clean, rigid fixing point for machine frames, guarding, workstations and enclosures while keeping hardware minimal and the installation straightforward.

Key Benefits

• Rigid floor anchoring: Stabilises frames and prevents movement or tipping under dynamic loads.
• Clean appearance: Compact footprint with concealed profile fasteners for a neat, professional look.
• Fast installation: Slot-8/M8 interface eliminates extra machining and speeds up assembly.
• Durable build: Zinc die-cast body with protective finish for long service life.
• Service-friendly: Frames can be repositioned or re-leveled without dismantling the whole structure.

System Compatibility

Designed for I-Type Slot 8 extrusion systems (40-series). Compatible with common I-Type ecosystems such as ITEM, ISB, ISP and other I-Type Slot-8 profiles using M8 hardware.

Typical Applications

• Anchoring machine frames and production cells
• Safety guarding, fences and door posts
• Workstations, racks and conveyor supports
• Metrology stands, test rigs and kiosks

How It Works

1. Slide the Roll-in T-slot Nut M8 into the profile slot and position the bracket at the base of the post.
2. Fasten the bracket to the profile, then align the frame.
3. Mark the floor holes, drill to suit your anchors (not included), and bolt the bracket to the floor.
4. Check alignment and torque to specification; repeat on remaining posts as required.

Product Features

• Slot interface: I-Type Slot 8 (40-series), M8 fasteners
• Material: Zinc die-cast body; steel hardware zinc-plated
• Finish: Black powder-coated for corrosion resistance and premium look
• Foot length: 160-class floor bracket suitable for upright posts and end frames
• Mounting: Through-holes for common mechanical floor anchors (select per substrate)

What’s Included

• 1 × Floor Bracket 160 (black coated)

Technical Notes

• Profile system: I-Type Slot-8 (40-series), M8 hardware
• Installation: Use floor anchors suitable for the base material (concrete, steel, etc.)
• Loads: Actual capacity depends on profile size, number of brackets, anchors and floor substrate—verify with your structural requirements and the product datasheet.

Selection & Compatibility Checklist

• Confirm your profiles are I-Type Slot-8 (40-series)
• Choose floor anchors for your substrate (not supplied)
• Verify clearance for drilling and tool access at the base
• Plan the number of brackets per frame upright to meet load and stability targets

Why Choose This Floor Element?

Compared with improvised base plates, the Floor Bracket 160 delivers a tidy, standardized mounting solution that matches the aesthetic and mechanical interface of your I-Type profile system—reducing build time and improving long-term serviceability.
